different thickness pmma plexiglass transparent extruded clear cast acrylic sheet
different thickness pmma plexiglass transparent extruded clear cast acrylic sheet
·Application:Advertising Sheet, Decoration, Engraving etc
·Density: 1.2g/cm
·Color:Transparent/clear, colored for choose
·Packing: Per sheet: Both sides covered with kraft paper to protect surface
·Surface: High hardness and glossy
·Density: 1.2g/cm
·Color:Transparent/clear, colored for choose
·Packing: Per sheet: Both sides covered with kraft paper to protect surface
·Surface: High hardness and glossy
On sale：
$1.60
Price：
$2.40
shared：
Transparent/clear, colored for choose
1250*1850,1250*2450,1050*2050,2050*3050 etc
1.2g/cm3
Different thickness pmma plexiglass transparent extruded clear cast acrylic sheet
The production process of acrylic extruded boards is to first melt the acrylic raw materials and then extrud them at high temperature through mechanical equipment.
| Width*Length(mm) | Thickness(mm) | Density | Color |
| 1250*1850,1250*2450,1050*2050,2050*3050 etc... | 1-200 | 1.2 | As requirement |
In order to offer a good price, we need your kindly help to confirm us about the following details as the reference
1. Color (transparent, semitransparent, white, black, red, blue, green and as per customer's requirement)
2. Thickness (2mm~30mm)
3. Size (1220x2440mm standard)
4. Quantity to check the delivery time
|
|
|
| Types | Items | Units | Value | Test method |
Mechanical Characteristics | Elasticity Modulus | kg/cm2 | 28000 | ASTM D-638 |
| Curving Intensity | kg/cm2 | 1260 | ASTM D-790 | |
| The Curving elasiticity rate | kg/cm2 | 28000-35000 | ASTM D-790 | |
| Compressing Intensity | kg/cm2 | 1260 | ASTM D-695 | |
| Lzod(Notched) | kg/cm2 | 0.4 | ASTM D-256 | |
| Rockwell Hardness | ft-lbs/in | M-100 | ASTM D-785 | |
Heat Characteristics | Moulding temperature | ℃ | 150 | |
| Transfigurating temperature | ℃ | 100 | ASTM D-648 | |
| Intenerating point | ℃ | 112 | ASTM D-1525 | |
| Line expanding modulus | cm/cm/℃ | 54*10-6 | ASTM D-696 | |
| Self extinguishing temperature | cm/cm/℃ | 64*10-6 | Cenco-Fitch | |
| Specific heat | ℃ | 4436 | ASTM D-1929 | |
| Flection rate | ℃ | 0.35 | (BTU/lboF) | |
Optical Characteristics | Flection rate | 1.49 | ASTM D-542 | |
| Light transmission rate | % | 92 | ASTM D-1003 | |
Others | Water absorbing rate | 24hrs | 0.3 | |
| Smell | none | |||
| Gout | none |
